| Item | Specification | Remark |
|---|---|---|
| Nominal Capacity | 102Ah | 0.2C discharge |
| Minimum Capacity | 100Ah | 0.2C discharge |
| Nominal Voltage | 12.8V | - |
| End Voltage | 10V±0.1V | - |
| Charging Current (Std.) | 20A | Ambient temperature 0~+40ºC |
| Charging Current (Max.) | 100A | Ambient temperature 0~+40ºC |
| Charging Voltage | 14.40±0.25V | - |
| Charging Time (Std.) | 6~7.0 hours | - |
| Discharging Current (Std.) | 20A | Ambient temperature -20~+60ºC |
| Max Continues discharge current | 100A | Ambient temperature -20~+60ºC |
| Battery Pack Resistance | <120mΩ | AC Impedance 1KHz |
| Battery Pack Weight | 15kg±500g | - |
